HARDWARE FEATURES
Standards and Protocols:
IEEE 802.3i
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
IEEE 802.1q
IEEE 802.1p
Interface:
24 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: No
Power Supply:
100-240VAC, 50/60Hz
Dimensions ( W x D x H ):
11.6 x 7.1 x 1.7 in.
(294 x 180 x 44 mm)
Mounting: Rack Mountable
Max Power Consumption: 14.19W (220V/50Hz)
Max Heat Dissipation: 48.39 BTU/h
PERFORMANCE
Switching Capacity: 48Gbps
Packet Forwarding Rate: 35.7Mpps
MAC Address Table: 8K
Packet Buffer Memory: 4.1Mbit
Jumbo Frame: 10KB
