TP-LINK

TP-LINK EAP115-WALL ACCESS POINT 300MBPS

TP-LINK

TP-LINK EAP115-WALL ACCESS POINT 300MBPS

DESCRIPTION:

  • Easy-mount construction allows installation into any standard EU-type data wall-box
  • Compact, low-profile design fits discreetly with any existing interior style
  • Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs
  • Support Power over Ethernet (802.3af) for convenient and affordable installation
  • Enterprise class Wi-Fi security helps to decrease network security threats
  • Captive portal provides one convenient method of authentication for Wi-Fi guests
  • Supports management vlan for an enhanced network management
HARDWARE FEATURES
Interface10/100Mbps Ethernet (RJ-45) Port *2
Physical Security Lock-
ButtonLED/Wi-Fi Button?RESET
Power SupplyPoE(IEEE 802.3af)
Power Consumption2.8 W
Dimensions ( W x D x H )3.4×3.4×1.2 in. (86.8*86.8*30.2 mm)
Antenna TypeInternal 2*1.8dBi Omni
MountingWall Plate Mounting
Hardware Watch DogYes
WIRELESS FEATURES
Wireless StandardsIEEE 802.11n/g/b/a
Frequency2.4GHz
Signal Rate11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Transmit PowerCE:
<15dBm(2.4GHz)
Wireless FunctionsMultiple SSIDs(Up to 8 SSIDs)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless SecurityCaptive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Local LAN port based VLAN
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,
WPA-PSK / WPA2-PSK
MANAGEMENT
Omada AppYes
Centralized Management• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Cloud AccessYes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Email AlertsYes
LED ON/OFF ControlYes
Management MAC Access ControlYes
SNMPv1,v2c
System Logging Local/Remote SyslogLocal/Remote Syslog
SSHYes
Web-based ManagementHTTP/HTTPS
L3 ManagementYes
Multi-site ManagementYes
Management VLANYes
OTHERS
CertificationCE, RoHS
Package Contents300Mbps Wireless N Wall-Plate Access Point EAP115-Wall
Installation Guide
Mounting Screw
System RequirementsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10
EnvironmentOperating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
