Connector(s)
1 - Connector Type(s)
3.5 mm Mini-Jack (3 Position)
3.5 mm Mini-Jack (4 Position)
3.5mm Mini-Toslink (SPDIF, Optical)
USB Type-A (4 pin) USB 2.0

Environmental
Operating Temperature
0°C to 60°C (32°F to 140°F)
Storage Temperature
0°C to 70°C (32°F to 158°F)
Humidity
10~90% RH (Non-Condensing)

Hardware
Bus Type
USB 2.0
Chipset ID
Cmedia CM6533

Indicators
1 - LED Indicators
Power
3 - LED Indicators
Playback / Recording sample rate

Performance
Audio Specifications
96 KHz / 24-bit Sample Rate, Approx 91dB SNR (A-weighting), 16-100ohm Headphone Drive Ability

Physical Characteristics
Weight of Product
33 g [1.2 oz]
Color
Black
Material
Plastic
Cable Length
40.6 cm [16.0 in]
Product Length
47 mm [1.9 in]
Product Width
46 mm [1.8 in]
Product Height
16 mm [0.6 in]

Power
Power Source
USB-Powered

Software
OS Compatibility
Windows® XP, Vista, 7, 8, 8.1, 10
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS X® 10.6 to 10.8

Note: DTS pass-through is supported in Windows 8, 8.1, and 10 only

Special Notes / Requirements
System and Cable Requirements
Available USB Port
Note
5.1 surround sound output is supported in Windows only
Microphone is stereo only.
